CM 1000 E

Ausstattung

ASA-LIFT CM-1000E    Road transport width Road transport width exceeding 3.3 m but less than 3.5 m   A.10.220 Hydraulic supply Hydraulic supply to the cylinders from the tractor hydraulics, two additional pumps incl. oil cooler for hydraulic motors driven by PTO shaft   A.10.205 Drive shaft (splines) Drive shaft 1 3/8" with 6 grooves   A.30.010 Automatic depth control Automatic depth control    A.30.115 Torpedoes Hydraulically driven torpedoes with rigid, angled tip    A.30.140 Overload safety device for torpedoes Overload safety device (shear pin) to protect torpedoes   A.30.145 Speed adjustment for torpedos Speed adjustment of torpedoes manual via flow control valve   A.30.210 Stone protection Mechanical stone protection (spring) to protect the share   Side shift of intake Without   Length of pick-up belt Pick-up belt, length 335"   A.40.112 Pick-up belts Pick-up belts, grooved surface "PK5"   A.40.915 Speed adjustment top lifter belt Speed adjustment of top lifter belt from the cab   A.40.920 Reversing function of the top lifter belt Reversing function of the top lifter belt   A.40.125 Height adjustment of top lifter belt Height adjustment of the top lifter belt in relation to main frame, hydraulically operated from the cab   A.40.210 Root cleaners 2x Hydraulically driven rotating root cleaners   A.40.220 Speed adjustment of the root cleaners Speed adjustment of root cleaners manual via flow control valve   A.40.140 Belt cleaner Spring-loaded belt cleaners at the rear deflection   A.50.010 Cutting unit Cutting unit driven by one hydraulic motor   A.50.050 Speed adjustment of cutting unit Speed adjustment of cutting unit manual via flow control valve   A.50.905 Lubrication system for cutting unit Lubrication strip for cutting unit   A.50.110 Rotating shaft below cutting unit Hydraulically driven rotating shaft below cutting unit to prevent accumulation of soil   A.50.200 Width of cross conveyor Width of cross conveyor 550 mm    A.50.210 Model of cross conveyor Cross conveyor, pitch 28 mm, rubber Covered   A.50.215 Speed adjustment of the cross conveyor Speed adjustment of cross conveyor manual via flow control valve   A.50.225 Agitating device in cross conveyor Hydraulically driven eccentric agitator in the cross conveyor   Picking table Without   Picking web model Without   Agitating device in picking table Without   Speed adjustment picking table Without   Operator unit at picking table Without   Platform Without   Fixture for boxes / bags Without   Drop height reducer fitted to picking table Without   Box width Without   Box height Without   Box length Without   Support wheel for box supply magazine Without   A.60.225 Cart elevator Cart elevator with hydraulically adjustable centre section and hydraulically adjustable elevator head   Width of overloading elevator Width of cart elevator 630 mm   A.60.235 Elevator belt version Elevator web with canvas, incl. driving fingers (flights), distance 140 mm   A.60.245 Speed adjustment of cart elevator Speed adjustment of cart elevator from the cab   A.60.325 Model of elevator head Hydraulically foldable drop height reducer, fitted to elevator head   A.70.120 Rear wheels Wheels 400 x 15.5    A.80.210 Operator unit Operator unit "i6" for switching on / off hydraulic features   A.90.100 Lighting Road lights and warning boards    A.90.120 Beacon light Beacon light    A.90.142 Working lights 2 x LED-working lights    A.90.990 Transport width reduction Transport width reduction: Top lifting unit is disassembled.
